Core Roller Veneer Dryer machine
1.Professional factory production
2.support ODM/OEM
3.Stable equipment and low failure rate
4.The dryer output is 2-3 times that of the original traditional dryer
5. The veneer is flat and wrinkle-free after drying
Veneer dryer is used in wood processing industry. The moisture content of veneer after rotary cutting is very high, and the veneer must be dried to meet the requirements of gluing process. Therefore, the veneer after rotary cutting needs to be dried naturally or dried by using the veneer dryer before it can be used.
The veneer dryer machine adopts frequency conversion speed regulation, which can adjust the feed speed according to the veneer thickness and moisture content to achieve the ideal drying effect. Higher thickness of roller walls ensuring longer life without getting distorted and smoother dried veneer. Veneer dryer machine is composed of transmission room, drying room, cooling room and other parts. This equipment highlights less investment and cost-effective advantages.
Advantages of Veneer Dryer Machine
1. The well-developed heat exchange system fully improves the energy utilization rate and saves unnecessary energy waste.
2. The control cabinet has automatic temperature control and speed regulation system, which can accurately control the final moisture content. Simple operation and low failure rate.
3. The temperature in the burner is 40-60 ℃ higher than that of the traditional dryer (steam, thermal oil), and the temperature is controlled at 140-180 ℃, which shortens the drying time and increases the output.
4. After drying, the veneer is smooth, with no cracks, wrinkles, or end ripples.
5. Shrinkage and hardening are kept to a minimum and veneer collapse and honeycomb structure are avoided.
6. We have a professional R&D team which can design different models according to customer’s special requirement.
7. The perfect after-sale service team can supply 24 hours online service.
Product Parameters of Veneer Dryer
Model No | GTH30-40 |
Working Width | 3m |
Deck | 2 |
Roller material | Q235B, φ89 steel pipe |
Heating area length | 36m |
Cooling area length | 4m |
Veneer thickness | 0.8-8mm |
Veneer water moisture | Fresh veneer to about 10% |
Heating material & drying temperature | Waste wood, 140-200°C adjustable. Temperature control accuracy ±5°C. There is automatic temperature control and speed regulation system, which can guarantee the moisture content is consistent. |
Drying capacity (m³/24h) | 55-65cbm |
Veneer transport speed | 5-22m/min，16A chain |
Hot air blower | Power:5.5KW（9pc） |
Traction motor | Power: 7.5KW，frequency control（2pc） |
Cold air blower | Power: 5.5KW（1pc） |
Air intake fan | Power : 11KW（2pc） |
4 ton biomass burner | Power: 16.5KW |
Total power | 108.5KW |
Actual electricity consumption | About 76kwh per hour |
Customer Case
The Factory
Packaging & Shipping
